3.常規參數
|
NEC 吸波材料系列 specifications
|
|
技術參數 Features
|
標準規格 Standard specifications
|
高磁導率 High magnetic permeabillity type
|
***磁導率 Extra high magnetic permeabillity type
|
阻燃型Flane retardant type.無鹵素red phosphorus free type
|
高頻技術參數High frequency specification
|
|
型號 Type
|
EFR
|
EFX
|
EFF
|
EFA
|
EFG
|
|
有效頻率 Effective Frequency
|
Up to 10Ghz
|
|
工作溫度Operating temperature ℃
|
-40 to 105
|
|
厚度 Thickness （mm）
|
0.05,0.1,0.2,0.3,0.5,1.0
|
0.05,0.1,0.2,0.3,0.5
|
0.1,0.2,0.3
|
0.05,0.1,0.2,0.3
|
0.05,0.1,0.2,0.3
|
|
標準尺寸 Standand Dimentions (mm)
|
240*240
|
240*240/Roll acceptable
|
240*240
|
|
比重 Specific gravity
|
2.8(typ.)
|
3.2(typ.)
|
3.6(typ.)
|
3.1(typ.)
|
3(typ.)
|
|
抗張強度 Tensile strength (Mpa)
|
3.6(min.)
|
6.8(min.)
|
6.9(min.)
|
6.8(min.)
|
3.5(min.)
|
|
表面電阻 Surface resistance Ω
|
1.0*106
|
1.0*106
|
1.0*106
|
1.0*106
|
1.0*106
|
|
導熱系列 Thermal conductivity(W/m.k)
|
0.22
|
0.22
|
0.4
|
1.3
|
0.22
|
|
認可標準 Approved standard
|
UL94 V-0
|
-
|
UL 94 V-0
|
UL 94 V-1
|
|
UL FIEL NO.E176124
|
-
|
UL File No.e176124
|
|
環境Environment
|
ROHS
|
符合 Compliant
|
|
其它 Others
|
無鹵素，不含聚氯乙烯，無鉛Halogen free,PVC free,Lead free
|
阻燃，無鹵素，不含不含聚氯乙烯，無鉛 Red phosphorus free,Halogen free,PVC free,Lead free
|
無鹵素，不含不含聚氯乙烯，無鉛Halogen free,PVC free,Lead free
|
阻燃，無鹵素，不含不含聚氯乙烯，無鉛 Red phosphorus free,Halogen free,PVC free,Lead free
|
無鹵素，不含不含聚氯乙烯，無鉛Halogen free,PVC free,Lead free
|
|
相對磁導率 Relative magnetic permeabillity(at 1MHz）
|
60
|
100
|
130
|
60
|
20
|
|
備注 remarks
|
60的高磁導率及各種厚度、阻燃 u60 high pemeabillity various thickness,Flame retardant (UL 94 V-0 Certified)
|
100的高磁導率及各種厚度可供選擇，u100 high pemeabillity Various tihckness
|
行業的無鹵磁導率復習材料。阻燃。industry&＃39;s highest magnetic pemeabillty of u130 with halogen free composition.flame retandant(UL 94 V-0 certified)
|
60的高磁導率，無鹵阻燃，u60 high permeabillity.Red phosphorus free. flame retardant (UL 94 V-0 certified)
|
良好的抑制高頻在無線上網和更高寬帶的干擾excellent suppression of high-frequency noise in Wi-Fi and higher bandwidths.
|
|
|
4.用途及應用
扁平電纜和柔性線路板，手機，集成電路和，PCB,IC卡，DVD/VCD,PC電腦外圍設備,PDA掌上電腦，藍牙，移動電話。無線天線等。
掃描儀，微型電動機，FPC軟性線路板，Wi-Fi無線網絡，筆記本電腦的CPU 或NFC手機，無線局域網、PDA、PC、數碼相機等
微波通訊設備，光纖通訊技術，LNB高頻頭,BOX屏蔽箱,ITS智能交通系統，衛星系統的高頻頭，光學傳輸，無線天線等
|
