Mobile Crusher is widely used in mining, construction materials, road, rail way and hydropower industries, etc.
Mobile Crusher:The Mobile Crusher (mobile crushing and screening plants) is applied to multistage crush large materials, and then screen the discharges according to their different specifications. The whole set plants is widely used to mine, building material, highway, rail way and hydropower industries, etc., finish crushing and screening operations at one time, produce required size and output for consumers.
Features and Benefits:Highly Mobility:The Mobile crusher is short, and crusher equipments of each one is installed on independent movable base plate, on which the distance between shafts is short, it is of small turning radius, so it can move flexibly on general roads both operating area;Low Transportation Cost:Mobile crusher can process material on the scene without moving material to other area, which will decrease the transportation cost greatly;Directive and Effective Function:Integrative mobile crusher series can be used respectively, we can also supply more flexible technology and collocation to satisfy all kinds of requirements of movable crushing and screen, which make general organization and logistic transportation more direct and effective and cost decreased to lowest point;Flexible Combination and Good Adaptability:mobile crusher can be assembled into machine like ‘screening after crushing’ or ‘crushing after screening’ according to different crushing technology, crusher plant can be assembled into coarse crushing,fine crushing two-section crushing and screening system according to practical requirements , also can be assembled into coarse crushing, medium crushing and fine crushing tri-section crushing and screening system, even can operated respectively, which is of much flexibility;Whole Set Machine:Installation of integrative machine set eliminates assembling in complex situations and decrease material and working time expense. Reasonable and compact layout increases flexible station of plant.
Mobile Crusher Technical Data:
| Model | YDSPS-100 | YDSPS-150 | |
| Capacity(t/h) | 100 | 150 | |
| Max Feeder(mm) | 500 | 630 | |
| Hopper(m3) | 12 | 15 | |
| 1#frame |
Feeder | ZSW-380×96 | ZSW-490×110 |
| Jaw Crusher | PE-600×900 | PE-750×1060 | |
| Frame size (L×W×H) (mm×mm×mm) |
12894×2574×4078 | 11800×2950×4165 | |
| 2#frame |
Cone crusher | PYB-1200 | Null |
| Impact crusher | Null | PF-1315 | |
| Frame size (L×W×H) (mm×mm×mm) |
12400×2500×4189 | 8000×2794×4069 | |
| 3#frame | Shaker | 3YA-1548 | 3YK-1860 |
| Frame size (L×W×H) (mm×mm×mm) |
8640×2500×4046 | 9641×2730×4046 | |
